RSIC-Joist Isolator® Sound Isolation Clip
RSIC-Joist Isolator®
The RSIC-Joist Isolator® is designed to support framing members and float the framing member from the surrounding structure. A raised floor isolated with the RSIC-Joist Isolators improves low frequency definition. The RSIC-Joist isolator has 1/8" deflection with a 1000 lb load.
Spacing is max 16" x 72" or 24" x 48" oc.
RSIC, the Low Cost, High Performance,
Noise control Solution
Wood
Apartment
Recording Studio
Steel
Condo
Home Theater
Metal Deck
Commercial
Commercial Theater
Concrete
Retail
Conference Rooms
RSIC-Joist Isolator® dimensions
RSIC-Joist Isolator® dimensions
RSIC-Joist Isolator specifications: |
|
| Acoustical design load: | 1000 |
| Total deflection | 3 mm |
| Double deflection | N/A |
| Low VOC treated | Yes |
| Adjustable | No |
| Cavity min | 3.5" |
| Cavity max | No limit |
| Adjustment limit | Joist size min. 2x4 |
| Use on floors | Yes |
| Use on walls | No |
| New Construction | Yes |
| Retro Fit | Yes |
Spacing 24" x 48" oc. Max. Positioned parallel or perpendicular over joist.
Spacing 16" x 72" oc. Max. Positioned parallel or perpendicular over joist.
